Swan 651 1982-1991

Race Day 4

The Swan 651 was produced by Nautor’s Swan from 1983-1991 and replaced the S&S Swan 65 in the model range. Designed by Germán Frers, the Swan 651 blended the latest technology from Grand Prix Maxi and Whitbred design with the high quality craftsmanship of Nautor’s Swan. The result was a performance hull with high volume and excellent sea keeping characteristics.

GENERAL DIMENSIONS

Loa: 19.98 m 65.55 ft
Lwl: 16.80 m 55.12 ft
Beam: 5.30 m 17.39 ft
Draft: 3.5 m 11.5 ft
Ballast: 14400 kg 31700 lbs
Displacement: 36000 kg 79300 lbs

ON BOARD SYSTEMS

Fuel: 1100 l 290.6 USg
Engine: Perkins 6.3544 86.5 kW 116 SHP at 2800 rpm

SAIL PLAN

I: 26.80m 87.93 ft
J: 8.05 m 26.41 f
P: 20.40 m 80.05 ft
E: 7.06 m 23.16 ft
Fore triangle: 107.9 m2 1161.1 sq.ft
Main: 86.1 m2 927.1 sq.ft
Genoa 150%: 161.8 m2 1741.6 sq.ft
Spinnaker: 388 m2 4180 sq.ft
